Description
Vacuum Glass Lifter able to lift, rotate, and tilt sheets of glass manually in vertical direction
Operated by compressed air and with a sturdy structure, the Vacuum Glass Lifter AVGLP4-MR-250 is able to lift, tilt and rotate glass sheets manually in vertical directions at all angles. In addition, extended bars are equipped to widen the lifting coverage area.
Features
- Tilt in two directions: horizontal and vertical from 0 to 90°
- Manually rotate by 360° vertically
- Stainless steel back-up vacuum tank ensures safety in the event of an unexpected power outage
- Automatic vacuum pumping if vacuum loss occurs
- Audio/visual alarm system
- Attach/release material with an ON/OFF slide valve
- Independent battery power
Specifications
| Metric (mm-kg) | Imperial (inch-lbs) | |
| Pad diameter | Seal to seal:280 | 11 |
| Number of pads | 4 | – |
| Working load limit | 250 | 551 |
| Net weight | 81 | 178.6 |
| Gross weight | 98 | 216 |
| Packaging dimension | 1480x380x1190 | 58x15x46.9 |
